@novainfra7: This infographic illustrates a complete car fuse box wiring and power distribution system that safely delivers electricity from the battery to various vehicle parts. Core Components • Main Fuses: High-amp fuses (100A and 150A) protect the main power input from the battery. • Blade Fuses: Smaller fuses (5A to 30A) protect individual circuits like the horn, headlights, and fuel pump. • Relays: Electromechanical switches control high-load systems like the radiator fan and A/C compressor. • Power Distribution Busbar: Copper strips distribute incoming power evenly across the circuits. Blade Fuse Amperage & Colors • 5A: Tan • 10A: Red • 15A: Blue • 20A: Yellow • 25A: Clear • 30A: Green Wire Color Legend • Red: Battery power (always ON) • Yellow: Ignition power (ON) • Blue: Switched output from relays • Green: Sensor and control circuits • Black: Chassis ground If you want, tell me: • Are you troubleshooting a specific electrical problem in your car? • Do you need help finding the amperage for a specific part? I can help you narrow down the issue.#AutoAcademyOffical #DashboardLights #Auto #CarTips #AutomotiveEngineering
